GNET Systems G-ON2K / 2 Channel Dash Cameras 2K Front + FULL HD 128GB - FULLY INSTALLED

   Outstanding Visibility under the Starlight

The STARVIS is back-illuminated pixel technology used in CMOS image sensors for surveillance camera applications.It features a sensitvity of 2000 mV or more per1 um2(color product, when imaging with a 706cd/m2 light source,F5.6 in 1 s accumulation equivalent), and realize high picture quality in the visible-light and near infrared light regions.




   3 functions for safe driving

ADAS



"ADAS update"
ADAS is a safe driving assistance system for the driver's safe driving environment


FVSA
Front Vehicle Start Alarm


FCWS
Forward Collision Warning System


LDWS
Lane Departure Warning System

The vehicle in front of you is pullingaway more than 2 meters, the dash cam let thedriver know with the beep sound also the departure icon on the LCD screen.



If the distance of the vehicle in front of you isreducing rapidly in short time with high speed,the dash cam let driver know with the beep sound anddisplay collision warning icon on the LCD screen.*Non-LCD product provides sound warning only

If you leave the lane while driving,the dash cam let the driver know withbeep sound and it shows yellow or red linesfor notification on the LCD screen.*Non-LCD product provides sound warning only


* Warning icons for lane detection, forward departure and collision are only visible if the LCD is on.ADAS settings are available when the GPS is connected.


Available for long parking records
TIME LAPSE



Time-lapse function automatically applied when entering parking mode



Time Lapse mode records one frame per second, minimizing the size of the video for a long time to record parking.



   Video codec(HEVC)
*HEVC(High Efficiency Video Coding)

H.265



H.265 compression rate is up to 2 times higher than H.264.
It means that users can use 256GB SD card as 512GB SD card.







   Clear recording quality when driving at night

REAL HDR



Real HDR is installed to remove light blurring when driving at night,
and it shows clear recording quality in various lighting conditions such as backlight and tunnels.






   Optimal viewing angle without distortion

WIDE VIEWING ANGLE


Front camera: 140 degrees / Interior I R camera(driver, passenger): 180 degrees / Rear camera: 140 degrees




The Excessive angle of view refracts the image, causing side effects such as distortion and loss of distance.
The GNET system has an optimal shooting angle of 140 degrees and Interior I R With a 180-degree angle of view without this problem,
the situation of side accidents is recorded more reliably, and images without distortion of left / right / up / down are provided.




   Smartphone link via Wi-Fi

G-NET APP


User-friendly GUI

User convenience has been further upgraded
using intuitive icons for anyone to operate conveniently









User-focused Firmware Upgrade

All the features you need at once! Easy and convenient GNET APP

Customized configuration by APP

After accessing the firmware configuration by APP, the latestfirmware can be automatically searched for and downloaded.
You can easily set up device registration,real-time video setup, recorded video list, and customer supportthrough the main screen.
Using the Smartphone APP, you can upgrade the firmware and play video as well as configure various settings








*Disable IOT/WiFi feature when CLOUD is enabled



   For vehicle battery discharge protection

LBP FUNCTION



It is an intelligent Safe Guard function that automatically shuts down recording when the voltage falls below
a specified voltage and cuts off the power to protect the battery of the vehicle.




LBP FUNCTION AUTO SAFE GUARD ( LBP ON / OFF )

Settings can be made directly from the dedicated GNET PC VIEWER, and the vehicle voltage can be checked when checking
the recorded video of the vehicle. You can easily set up wirelessly via GNET APP at the time of smartphone interlocking


Configurable Voltage (V)
Power Off
11.3
11.5
11.8
 12.0
12.3



   Convenient and diverse functions

FUNCTION

HIGH TEMPERATURETEST PASS

MEMORY CARD AUTOMATICRECOVERY AND SELF-FORMAT

BUILT-IN VOICE GUIDEAND MICROPHONE

G-Net has been passed the high-temperature test.Differs from other brand dash cameraswhich shut down the power because they cannot withstand high temperatures.

Unlike other companies' black boxes, whichrequire users to format periodically, JDR'sown file system with excellent reliability isapplied for convenient use without regular format.
It has a friendly voice guide, high-qualityvoice recording, and a high-performancemicrophone, which makes it easier to check theoperation and recording conditions while driving.

SECURITY LED FUNCTION

EXTERNAL GPS

VARIOUS RECORDING MODES

It is equipped with intelligent securityLED function to prevent crimes that can parkingterrorism and theft. With a clear view, it detectsmovement in parking mode and startsrecording automatically.

You can check at a glance the data imagereceived from the GPS while driving.* External GPS is optional (sold separately)

Parking Surveillance / Motion DetectionThe event recording is automatically recordedfor a certain period of time when the impact isdetected on the vehicle in variousrecording modes.



   PC exclusive viewer program

GNET PC VIEWER



Easily play and the check recorded video with a viewer program for PC

It provides various functions Zoom, partial zoom function, Lane drawing function, set recording frame.Backup features include AVI file generation, tampering prevention, thumbnails, and interval repetitive searches.







Image Sensor SONY Starvis
Audio input Built-in Microphone

Video Compression
H.265
Audio Compression
ADPCM
Resolution
Front : QHD 1440P / Rear : FHD 1080P (1920 X 1080)
Frame Rate
All cameras : Max. 30 FPS
Wi-Fi Smartphone Connection
Connect to GNET Smart phone application via Wi-fi dongle
G-Sensor
Event recording by External Shock
Speaker
Operation Status alarm / Voice guidance
External GPS
Synced with Google map, Keep track of location and Speed
Angle Of View
Front : 140˚, Rear : 140˚
Viewer
Windows XP/7/8/10, Support 32Bit / 64Bit, Synchronizing Google map with PC viewer is supportedover Windows7 and explorer 10 as per Google' s policy.
Power
DC 12V - 24V
Acceptable current valueof the supplied fuse
3A

Operation Temperature
-20℃ ~ 60℃
Humidity
10~95%
Dimension(WxHxD, mm)
Front : 116x56x32, Rear : 44x38x28
