IROAD FX2 Full HD 2 Channel Dash Cameras

iRoad



EXCELLENCE IN SIMPLICITY
IROAD DASH CAM FX1

1CH FHD | Built-in GPS | ADAS 2.0Time Lapse | Hyper Lapse-4X Efficiency Recording | Wi-Fi | Night Vision140º Wide Viewing Angle | Battery Discharge Prevention | Format Free 2.2Mobile APP (Android/iOS) | Windows/Mac Viewer

NO MORE WORRIES ABOUT STORAGE
4X More Recording Time

LONG DRIVE RECORDING WITH
HYPER LAPSENo more worries about missing out while driving long-distance
 By compressing the recorded video, Hyper Lapse minimizes the memory space and saves 4 times more footage.
 However, when an event or impact occurs, recording frame rate switches automatically to 30 fps to provide clearer images of important moments.

LONG PARKING RECORDING WITH
TIME LAPSE
 Experience continuous Parking Mode recording for a long time with IROAD Time Lapse.
 Time Lapse is a low-capacity recording method that minimizes the storage space by compressing and saving at 1fps while in Parking Mode.
 On the other hand, when an impact or motion is detected during Parking Mode, it switches automatically to 30 fps to provide clearer images of important moments.
PARKING MODE
NORMAL
TIME LAPSE
CAPACITY
32GB
FPS
30 fps
1 fps
RECORDING TIME
About 4H
About 48H

ADAS 2.0(VER.2022)
ADVANCED DRIVER ASSISTANCE SYSTEM
The IROAD FX1 is equipped with the Road Safety Warning System that provides audio and visual alerts for Lane Departure (LDWS), Front Collision (FCWS) and Front Vehicle Departure (FVDW). It detects road markings and gives voice warnings to the drivers if the vehicle begins to stray from its lane or when it is at risk of an imminent crash.
COMPREHENSIVE DRIVING DATA THROUGH
BUILT-IN GPS
The GPS data in the IROAD FX1 can precisely pinpoint the vehicle’s location and routes on the map, while also displaying the driving speed. This helps to more accurately assess the situation and the circumstances in case of an accident.
1080P FHD 1CH
HIGH DEFINITION VIDEO QUALITY
CMOS Image Sensors allow constant FHD 1080p Front recording during both daytime and nighttime along with a 140-degree wide angle lens view. This will minimize blind spots to assure recording of all events without fail.

NIGHT TIME PICTURE QUALITY CORRECTION
NIGHT VISION
Videos recorded by a dash cam in low light environments such as dark alleyways or underground parking lots can pose difficulties when you try to accurately identify information from the image.IROAD NIGHT VISION employs the new ISP (Image Signal Processing) technology and the real-time image processing function to provide brighter images than our earlier models when recording at nighttime during Parking Mode.


LIGHT EXPOSURE
AUTOMATIC EXPOSURE
Sudden light exposure while driving, such as strong direct sunlight or the light of incoming vehicles at night, can sometimes affect your vision and make it difficult to assess the situation. The IROAD FX1 dash camera automatically adjust the amount of light exposure to provide bright and clear images in any situation.



VARIOUS AUTONOMOUS RECORDING MODES
CONTINUOUS RECORDING MODE
 This mode is activated automatically when you start the engine. Recorded videos are saved in one-minute segments with an auto-looping mechanism.
EVENT RECORDING MODE
 It will automatically start an Event recording when motion or impact is detected around the vehicle during both parking and driving mode.
MANUAL RECORDING
 Generate Event files on request when witnessing a traffic incident or something interesting on the road that you want to make sure you catch on camera. When pressing the Manual Recording button, the dash cam records and separately stores a few seconds of footage before (5-10s) and after (15-20s) that moment as a Manual Recording file protected from overwriting (limit before overwriting: up to max. 4% of total SD card storage).
PARKING IMPACT BUFFERED RECORDING
 When in Parking Mode, the built-in G sensor detects when an impact with the vehicle has occurred, for which the dash cam generates an event file stored separately, protected from overwriting (if SD card storage is assigned to Event files through the dash cam settings). The saved video will include a few seconds before the impact occurred (5-10s) and a few seconds after (15-20s). This can be turned ON regardless of the Parking Mode used (Time-lapse or Motion Detection).
TIME-LAPSE PARKING MODE
 The dash cam will continuously record at 1fps during Parking Mode. If Parking Impact is turned ON, the frame rate will briefly switch from 1fps to 30fps when recording the impact, then the dash cam will continue recording at 1fps.
MOTION DETECTION PARKING MODE
 The dash cam stays “asleep” until it detects movement around the vehicle. In this mode, any motion happening around the vehicle in recorded in an event file stored separately. The saved video will include a few seconds before the motion was detected (5-10s) and a few seconds after (15-20s).

IROAD MOBILE X-VIEW
ANYWHERE & ANYTIME, CONNECT THROUGH Wi-Fi
IROAD SMART VIEW (iOS/Android)
[COMPATIBILE WITH] (iOS/Android)DESIGNED FOR THE SMARTER USE OF IROAD DASH CAMS
The IROAD Mobile Application X-VIEW is free and allows you to save the dash cam’s footage as video or images directly on your smartphone.Also through the app you can access Live View, do backups, upload directly to social media and many other things, including automatically updating your dash cam’s firmware.









SEARCH 'IROAD' ON GOOGLE PLAYSTORE & APPLE APP STORE



IROAD PC X-VIEW
DETAILED SETTINGS AND FOOTAGE INFORMATION

 The intuitive and easy-to-use interface of IROAD PC X-VIEW offers a simple and convenient way to watch your recorded videos on your PC or Mac. You can playback and download recorded videos, as well as check your route history and driving speed data.


PARKING MODE WITH MINIMUM POWER CONSUMPTION
ENERGY SAVING 2.4W
In parking mode, power consumption is greatly reduced to maximize recording time. In addition, to protect the vehicle battery, the dash cam automatically powers off when the vehicle battery voltage falls below a certain set value (Battery Discharge Prevention).


HIGH DURABILITY
HIGH-TEMPERATURE PROTECTION
The FX1 models are built to endure both high and low temperatures in order to keep the device running smoothly. The high-temperature protection function makes the device automatically turn off in case of overheating, protecting both the device and the stored data.


HIGH-EFFICIENCY VIDEO CODING FORMAT
FORMAT FREE 2.2
The 2022 newly released IROAD FX2 dash cams use a new file format which allows for a higher compression rate, uses memory space more efficiently and provides outstanding image quality.Format Free 2.2 is a server storage technology developed by IROAD that maximizes the life span, stability and efficiency of memory cards.



RESOLUTION / FRAME RATE
Front-1080p Full HD @ 30fps / Rear1080p Full HD @ 30fps * Hyper-Lapse(Driving Mode) @ 1fps / Time-Lapse(Parking Mode) @ 1fps * Frame rate may vary during Wi-Fi streaming.

IMAGING SENSOR
Front: CMOS Sensor (Approx. 2MP) 1/2.8 inch / Rear: CMOS Sensor (Approx. 2MP) 1/2.8 inch

VIEWING ANGLE
Front: Diagonal 140°, Horizontal 116°, Vertical 61° Rear: Diagonal 140°, Horizontal 106°, Vertical 58°

GPS
Built-in GPS

WI-FI
External(2.4GHz)

IMPACT SENSOR
3-Axis Accelerometer G-Sensor (3D, ±3G)

ADAS 2.0
LDWS(Lane Departure Warning System) FVDW(Front Vehicle Departure Warning) FCWS(Forward Collision Warning System)

RECORDING MODES
Driving Recording (Continuous) Impact Recording, Parking Mode (Impact Recording + Motion Detection / Time-lapse) Manual Recording, Audio Recording

CAPACITY
microSD card up to 256GB

VIDEO

FORMAT FREE 2.2
YES (Adaptive)

LED INDICATORS
Front: Rec LED, GPS LED, Wi-Fi LED, Security LED Rear: Security LED

OPERATION TEMPERATURE
-20℃ – 70℃ (-4°F – 158°F)

STORAGE TEMPERATURE
-20℃ – 80℃ (-4°F – 176°F)

HIGH TEMP CUT OFF
Approx. 70℃ (158°F)

INPUT POWER
DC 12V~24V / DC 5V

CERTIFICATIONS
FCC, CE, RoHS, IC

PRODUCT DIMENSIONS
Front: W 108.2 mm x H 57 mm x D 32.9 mm (Weight 100g) Rear: W 59.6 mm x H 27.9 mm (Weight 30g)

SOFTWARE
IROAD X-View (PC) - Windows 7 or higher and Mac (OS X 10.7 64Bit) or higher

APPLICATION
IROAD X-View (Mobile) - Android 6.0, IOS 10.0 or higher : Firmware update supported
